Converge to MarkEnding
Rotate to Lockup
An object spins with a long ease-out and stops at the exact angle that forms the logo silhouette or the hero view of the product.
Seen in
Full recipe
Why it works
The last frame of the rotation is the logo, and the motion shows where the flat mark comes from in three dimensions. Rotation speed keeps dropping, so the last 0.8s is a slow approach to the target. The material uses only three gray tones with flat light, so the angle reads clearly.
Spec
- Timing
- Film 10s. Spin 0.2–2.7s (2.5s, 75 frames): 1.62 turns, about 1.5 of them in the first second; fade-in 0.2–0.42s; still hold 2.7–5.0s (2.3s, 69 frames). Hard cut at 5.0s to the fragment-assembly shot: three slabs fly in from 5.14s, 0.8s each (24 frames), staggered 0.08s; lockup 6.55–7.45s (0.9s, 27 frames); held to 10s
- Easing
cubic-bezier(0.16,1,0.3,1)(expo.out, normalized to end exactly at 1), no overshoot; rotation angle runs 1.62 turns × (1 − eased progress), and a tilt quaternion slerps to identity on the same curve; fly-in and lockup expo.out; fade-in smoothstep- Camera
- Fixed orthographic camera, object centered; the hexagon silhouette height grows 324px→432px (30%→40% of frame height) on the spin curve. In the second shot the assembled mark is 300px tall, then shrinks to 150px and steps left to make room for the wordmark
- Subject
- A cube cut into three stacked slabs (gap 0.05 of the edge) flips around a tilted view-space axis (0.62, 0.74, 0.26); the end pose is isometric (rotX 35.264°, rotY −45°) with a vertex pointing at the camera so the silhouette is a hexagon matching the logo. The slabs sit staggered along the view diagonal until the final angle lines them up; bevel and face gradient fade out as the stone stops. In the fragment shot the slabs enter from the lower left, right and top, rotating 1.35–1.5 rad and scaling 1.25–1.3x→1x
- Style
- Near-black background
#0b0b0c, three flat gray tones for three faces (top#ecebe7, darkest#5c5b58, left in between), no highlights; 180° shutter motion blur by sub-frame accumulation; wordmark Inter 600, 103px,#ecebe7
Prompt
Build a logo ending called Rotate to Lockup. Near-black background (#0b0b0c) and a fixed orthographic camera. A cube cut into three stacked slabs (gap 5% of the edge) fades in at the center over 0.2–0.42 seconds and flips around a tilted axis for 1.62 turns; use expo.out (cubic-bezier(0.16,1,0.3,1)) over 2.5 seconds (0.2–2.7s), so about 1.5 turns happen in the first second and the speed drops gradually, while its hexagon silhouette grows from 30% to 40% of frame height (324px to 432px). On the last turn the stone lands in an isometric pose (rotX 35.264°, rotY −45°) with one vertex pointing at the camera, lined up exactly with your logo outline; the slabs stay staggered along the view diagonal until that final angle. Hold still for 2.3 seconds with no overshoot. Use three flat gray tones for the faces (#ecebe7 top, #5c5b58 darkest, left in between), no highlights, with bevel and gradient only while it moves, and 180° shutter motion blur. At 5.0s cut to the second shot: the three slabs fly in from outside the frame starting 5.14s, 0.8 seconds each with expo.out, staggered 0.08 seconds, rotating into place and scaling from 1.3x to 1x to form a 300px mark. At 6.55s the mark shrinks to 150px and steps left over 0.9 seconds (expo.out) while the wordmark is uncovered from behind it (clip edge riding the mark, x −36px→0). Hold to 10s. Build it with Three.js: orthographic camera, custom flat-shaded material, rotation from an angle around a view-space axis plus a slerp from a tilt quaternion.
People describe it as
- The cube spins and turns into the logo
- It spins and stops at just the right angle
- Fragments fly in and form a ring
Often confused with
- Converge to MarkRotate to Lockup turns one object to a target angle; Converge to Mark gathers many elements and compresses them into one icon.
- Outline to SolidOutline to Solid goes from line to fill; in Rotate to Lockup the material stays the same and only the orientation changes.
